High-Quality and Robust Construction
Openwell submersible pumps are specifically designed to use in different applications in which the pump is completely immersed in water.
These pumps might be single-stage with an impeller or multistage-like borewell submersible pumps. These pumps are powered by a prime mover, which is often an electric motor. At Splendor Pump LLP, we manufacture our open-well submersible pumps with high-grade iron material with unique hydraulic designs to ensure better performance and efficiency.
You can use these pumps in the agriculture sector, community water supply, and irrigation from open wells. Being one of the leading Openwell Submersible Pump Manufacturers in India, we are engaged in providing a huge compilation of pumping solutions.
Various Models Of Openwell Sub. Pump
Splendor Pumps commenced operations in 1996, the company is embarked on a mission to produce quality risk, cost-efficient, reliable and durable Submersible Pumps & Cable for both Indian and overseas markets
PumpBuy from the Top Openwell Submersible Pump Suppliers in India
Higher Operating Efficiencies
Manufactured with high-grade raw materials and cutting-edge techniques, these pumps are as per market standards and rules. Additionally, we test these pumps as per a set of criteria and norms before the final delivery of the order.
Our pumps are made with ultra-modern and robust design, quality raw materials, and manufacturing processes to ensure longer life. These pumps are highly-efficient and energy-saving. We can also supply openwell submersible pump 5hp motor horsepower.
Furthermore, these items are accessible in a variety of sizes and supplies to meet the wants and desires of our consumers. Explore more submersible pumps at our website and request a free quote.
FeaturesTechnical Details
Higher Operating Efficiencies
Salient Features
Technical Specifications
Pump Material
Motor Material Product Feature
- Optimized hydraulic design for efficient performance.
- Rotor are grinding & burnished to give better surface finish value which ensure long life.
- Specially designed thrust bearing to withstand high axial load.
- Sleeve and thrust bearing designed for longer life.
- High operating efficiency & more durability and hygiene.
- Dynamically balances rotating parts to ensure minimum vibration and longer life.
- SS – 410 impeller available in mixed flow series.
- Designed for wide voltage applications.
- Starts easily at low voltage, easy installation and low maintenance.
| TECHNICAL SPECIFICATIONS | ||
|---|---|---|
| 1 | KW / HP RANGE | 3.70 / 5.00 TO 15.00 / 20.00 |
| 2 | VOLTAGE RANGE | 380 TO 440 VOLT ( THREE PHASE ) |
| 3 | DISCHARGE LPM | UP TO 1200 LITRE |
| 4 | HEAD | UP TO 225 METRE |
| 5 | PUMP DIA | 142 MM |
| 6 | MOTOR DIA | 142 MM |
| Pump Material | ||
|---|---|---|
| 1 | DIFFUSER | CAST IRON FG 200 GRADE |
| 2 | IMPELLER | NYLON / SS – 410 |
| 3 | CASTING PART | CAST IRON FG 200 GRADE |
| 4 | BUSH | GM LTB- 4 / NBR |
| 5 | PUMP SHAFT | SS – 410 |
| 6 | SLEEVE AND COUPLING | SS – 410 |
| Motor Material | ||
|---|---|---|
| 1 | MOTOR BODY | SS – J4 |
| 2 | MOTOR SHAFT | SS – 420 |
| 3 | CASTING PART | CAST IRON FG 200 GRADE |
| 4 | BUSH | CARBON / GM LTB – 4 |
| 5 | THRUST BEARING | CARBON V/S SS |
| 6 | STAMPING | SILICON STEEL |
| 7 | ROTOR | COPPER / ALU. PRESSURE DIE – CAST |
| 8 | WINDING | MULTI LAYER PVC INSULATED WIRE |
TechnicalSpecifications
Higher Operating Efficiencies
An ISO 9001:2018 Company
An Agricultural Pump Industry Since 1997
ApplicationApplication Area Where We Serve
Higher Operating Efficiencies
AGRICULTURE
AGRICULTURE
DOMESTIC
INDUSTRY
HOSPITAL
GARDEN
